Main body dimensions:
Diameter 60cm (23.7” in)
Height 38cm (15” in)
Combustion Chamber:
1.5 litre Capacity (Burns Up to 6 hours)
Height Adjustable Hanging System:
Mounting Plate:
Diameter 19 cm (7.5”in)
Height 2.5 cm (1”in)
Adjustable Hanging Pole:
6 height positions
• Full extension 142cm (56” in),
• Height Positions :134.5cm (53” in), 125.5cm (49.4” in),116.5cm (45.8” in),107.5cm (42.3” in)
• Minimum extension: 98.5cm (38.8“ in)
Maximum length of complete unit at full extension: 182.5cm (72” in)
This includes Mounting bracket at 2.5cm (1” in) high, Hanging Pole at 142cm (56” in) high and Cocoon at 38cm (15” in) high.
For high ceilings 25cm (10” in), 50 cm (20” in) and 100cm (40” in) extension poles are available.
For pitched or angled roofs angled mounting brackets are available (please see accessories)
Additional Mounting Plates are available so your Fireplace can be hung in various locations throughout your home:.
The units can rotate 360 degree.
Materials and Finish:
• Cocoon Shell: 316 Marine Grade Stainless Steel Mirror Finish.
• Mounting Bracket: 316 Marine Grade Stainless Steel Mirror Finish
• Hanging Pole: 316 Marine Grade Stainless Steel Hairline Finish.
• Combustion Chamber: 316 Marine Grade Stainless Steel Hairline Finish.
